FlashHobby Mars 2810 (M2810 1100KV) is a high-efficiency BLDC brushless motor designed for quadcopters and medium-power platforms that require stable thrust output, responsiveness and reliability under load. The 12N/14P configuration and 5 mm shaft deliver balanced performance and durability.
We are a veterans’ team
We evaluate hardware based on real-world operational use — thermal stability, load endurance, peak-current behavior and compatibility with different propeller classes — before recommending it for and quadcopter applications.
Technical specifications
| Parameter | Value |
|---|---|
| Motor type | Brushless (BLDC) |
| Model | M2810 |
| KV rating | 1100 KV |
| Configuration | 12N / 14P |
| Winding resistance | 0.064 Ω |
| Shaft diameter | 5 mm |
| Motor size | 34.3 × 25 mm |
| Weight (with cable) | 68.7 g |
| Nominal voltage | 3–6S LiPo |
| No-load current | 1.68 A @ 16 V |
| Peak current (60 s) | 55.62 A |
| Maximum power | 1384 W |
| Maximum thrust | 2837 g |
Comment
Well-suited for medium-weight builds and agile platforms that require fast throttle response and sustained stability under continuous flight load.
Suitable for
and quadcopter operators
Engineering and integration teams
Medium-class builds
Training and technical platforms
